Agent Metadata
With Agent Metadata, template admins can expose operational metrics from their workspaces to their users. It is the dynamic complement of Resource Metadata.
See the Terraform reference.
Examples
All of these examples use heredoc strings for the script declaration. With heredoc strings, you can script without messy escape codes, just as if you were working in your terminal.
Some of the below examples use the coder stat command. This
is useful for determining CPU/memory usage inside a container, which can be
tricky otherwise.
Here's a standard set of metadata snippets for Linux agents:
resource "coder_agent" "main" {
os = "linux"
...
metadata {
display_name = "CPU Usage"
key = "cpu"
# Uses the coder stat command to get container CPU usage.
script = "coder stat cpu"
interval = 1
timeout = 1
}
metadata {
display_name = "Memory Usage"
key = "mem"
# Uses the coder stat command to get container memory usage in GiB.
script = "coder stat mem --prefix Gi"
interval = 1
timeout = 1
}
metadata {
display_name = "CPU Usage (Host)"
key = "cpu_host"
# calculates CPU usage by summing the "us", "sy" and "id" columns of
# top.
script = <<EOT
top -bn1 | awk 'FNR==3 {printf "%2.0f%%", $2+$3+$4}'
EOT
interval = 1
timeout = 1
}
metadata {
display_name = "Memory Usage (Host)"
key = "mem_host"
script = <<EOT
free | awk '/^Mem/ { printf("%.0f%%", $4/$2 * 100.0) }'
EOT
interval = 1
timeout = 1
}
metadata {
display_name = "Disk Usage"
key = "disk"
script = "df -h | awk '$6 ~ /^\\/$/ { print $5 }'"
interval = 1
timeout = 1
}
metadata {
display_name = "Load Average"
key = "load"
script = <<EOT
awk '{print $1,$2,$3}' /proc/loadavg
EOT
interval = 1
timeout = 1
}
}
Utilities
top is available in most Linux distributions
and provides virtual memory, CPU and IO statistics. Running top produces
output that looks like:
%Cpu(s): 65.8 us, 4.4 sy, 0.0 ni, 29.3 id, 0.3 wa, 0.0 hi, 0.2 si, 0.0 st
MiB Mem : 16009.0 total, 493.7 free, 4624.8 used, 10890.5 buff/cache
MiB Swap: 0.0 total, 0.0 free, 0.0 used. 11021.3 avail Mem
vmstat is available in most Linux
distributions and provides virtual memory, CPU and IO statistics. Running
vmstat produces output that looks like:
procs -----------memory---------- ---swap-- -----io---- -system-- ------cpu-----
r b swpd free buff cache si so bi bo in cs us sy id wa st
0 0 19580 4781680 12133692 217646944 0 2 4 32 1 0 1 1 98 0 0
dstat is considerably more parseable than
vmstat but often not included in base images. It is easily installed by most
package managers under the name dstat. The output of running dstat 1 1 looks
like:
--total-cpu-usage-- -dsk/total- -net/total- ---paging-- ---system--
usr sys idl wai stl| read writ| recv send| in out | int csw
1 1 98 0 0|3422k 25M| 0 0 | 153k 904k| 123k 174k
DB Write Load
Agent metadata can generate a significant write load and overwhelm your database if you're not careful. The approximate writes per second can be calculated using the formula:
(metadata_count * num_running_agents * 2) / metadata_avg_interval
For example, let's say you have
- 10 running agents
- each with 6 metadata snippets
- with an average interval of 4 seconds
You can expect (10 * 6 * 2) / 4 or 30 writes per second.
One of the writes is to the UNLOGGED workspace_agent_metadata table and the
other to the NOTIFY query that enables live stats streaming in the UI.
