OIDC with Coder Sequence Diagram
.

By default, Coder is accessible via password authentication. Coder does not recommend using password authentication in production, and recommends using an authentication provider with properly configured multi-factor authentication (MFA). It is your responsibility to ensure the auth provider enforces MFA correctly.

The following steps explain how to set up GitHub OAuth or OpenID Connect.

GitHub

Step 1: Configure the OAuth application in GitHub

First, register a GitHub OAuth app. GitHub will ask you for the following Coder parameters:

  • Homepage URL: Set to your Coder deployments CODER_ACCESS_URL (e.g. https://coder.domain.com)
  • User Authorization Callback URL: Set to https://coder.domain.com

Note: If you want to allow multiple coder deployments hosted on subdomains e.g. coder1.domain.com, coder2.domain.com, to be able to authenticate with the same GitHub OAuth app, then you can set User Authorization Callback URL to the https://domain.com

Note the Client ID and Client Secret generated by GitHub. You will use these values in the next step.

Coder will need permission to access user email addresses. Find the "Account Permissions" settings for your app and select "read-only" for "Email addresses".

Step 2: Configure Coder with the OAuth credentials

Navigate to your Coder host and run the following command to start up the Coder server:

coder server --oauth2-github-allow-signups=true --oauth2-github-allowed-orgs="your-org" --oauth2-github-client-id="8d1...e05" --oauth2-github-client-secret="57ebc9...02c24c"

For GitHub Enterprise support, specify the --oauth2-github-enterprise-base-url flag.

Alternatively, if you are running Coder as a system service, you can achieve the same result as the command above by adding the following environment variables to the /etc/coder.d/coder.env file:

CODER_OAUTH2_GITHUB_ALLOW_SIGNUPS=true
CODER_OAUTH2_GITHUB_ALLOWED_ORGS="your-org"
CODER_OAUTH2_GITHUB_CLIENT_ID="8d1...e05"
CODER_OAUTH2_GITHUB_CLIENT_SECRET="57ebc9...02c24c"

Note: To allow everyone to signup using GitHub, set:

CODER_OAUTH2_GITHUB_ALLOW_EVERYONE=true

Once complete, run sudo service coder restart to reboot Coder.

If deploying Coder via Helm, you can set the above environment variables in the values.yaml file as such:

coder:
  env:
    - name: CODER_OAUTH2_GITHUB_ALLOW_SIGNUPS
      value: "true"
    - name: CODER_OAUTH2_GITHUB_CLIENT_ID
      value: "533...des"
    - name: CODER_OAUTH2_GITHUB_CLIENT_SECRET
      value: "G0CSP...7qSM"
    # If setting allowed orgs, comment out CODER_OAUTH2_GITHUB_ALLOW_EVERYONE and its value
    - name: CODER_OAUTH2_GITHUB_ALLOWED_ORGS
      value: "your-org"
    # If allowing everyone, comment out CODER_OAUTH2_GITHUB_ALLOWED_ORGS and it's value
    #- name: CODER_OAUTH2_GITHUB_ALLOW_EVERYONE
    #  value: "true"

To upgrade Coder, run:

helm upgrade <release-name> coder-v2/coder -n <namespace> -f values.yaml

We recommend requiring and auditing MFA usage for all users in your GitHub organizations. This can be enforced from the organization settings page in the "Authentication security" sidebar tab.

OpenID Connect

The following steps through how to integrate any OpenID Connect provider (Okta, Active Directory, etc.) to Coder.

Step 1: Set Redirect URI with your OIDC provider

Your OIDC provider will ask you for the following parameter:

  • Redirect URI: Set to https://coder.domain.com/api/v2/users/oidc/callback

Step 2: Configure Coder with the OpenID Connect credentials

Navigate to your Coder host and run the following command to start up the Coder server:

coder server --oidc-issuer-url="https://issuer.corp.com" --oidc-email-domain="your-domain-1,your-domain-2" --oidc-client-id="533...des" --oidc-client-secret="G0CSP...7qSM"

If you are running Coder as a system service, you can achieve the same result as the command above by adding the following environment variables to the /etc/coder.d/coder.env file:

CODER_OIDC_ISSUER_URL="https://issuer.corp.com"
CODER_OIDC_EMAIL_DOMAIN="your-domain-1,your-domain-2"
CODER_OIDC_CLIENT_ID="533...des"
CODER_OIDC_CLIENT_SECRET="G0CSP...7qSM"

Once complete, run sudo service coder restart to reboot Coder.

If deploying Coder via Helm, you can set the above environment variables in the values.yaml file as such:

coder:
  env:
    - name: CODER_OIDC_ISSUER_URL
      value: "https://issuer.corp.com"
    - name: CODER_OIDC_EMAIL_DOMAIN
      value: "your-domain-1,your-domain-2"
    - name: CODER_OIDC_CLIENT_ID
      value: "533...des"
    - name: CODER_OIDC_CLIENT_SECRET
      value: "G0CSP...7qSM"

To upgrade Coder, run:

helm upgrade <release-name> coder-v2/coder -n <namespace> -f values.yaml

OIDC Claims

When a user logs in for the first time via OIDC, Coder will merge both the claims from the ID token and the claims obtained from hitting the upstream provider's userinfo endpoint, and use the resulting data as a basis for creating a new user or looking up an existing user.

To troubleshoot claims, set CODER_VERBOSE=true and follow the logs while signing in via OIDC as a new user. Coder will log the claim fields returned by the upstream identity provider in a message containing the string got oidc claims, as well as the user info returned.

Note: If you need to ensure that Coder only uses information from the ID token and does not hit the UserInfo endpoint, you can set the configuration option CODER_OIDC_IGNORE_USERINFO=true.

Email Addresses

By default, Coder will look for the OIDC claim named email and use that value for the newly created user's email address.

If your upstream identity provider users a different claim, you can set CODER_OIDC_EMAIL_FIELD to the desired claim.

Note If this field is not present, Coder will attempt to use the claim field configured for username as an email address. If this field is not a valid email address, OIDC logins will fail.

Email Address Verification

Coder requires all OIDC email addresses to be verified by default. If the email_verified claim is present in the token response from the identity provider, Coder will validate that its value is true. If needed, you can disable this behavior with the following setting:

CODER_OIDC_IGNORE_EMAIL_VERIFIED=true

Note: This will cause Coder to implicitly treat all OIDC emails as "verified", regardless of what the upstream identity provider says.

Usernames

When a new user logs in via OIDC, Coder will by default use the value of the claim field named preferred_username as the the username.

If your upstream identity provider uses a different claim, you can set CODER_OIDC_USERNAME_FIELD to the desired claim.

Note: If this claim is empty, the email address will be stripped of the domain, and become the username (e.g. [email protected] becomes example). To avoid conflicts, Coder may also append a random word to the resulting username.

OIDC Login Customization

If you'd like to change the OpenID Connect button text and/or icon, you can configure them like so:

CODER_OIDC_SIGN_IN_TEXT="Sign in with Gitea"
CODER_OIDC_ICON_URL=https://gitea.io/images/gitea.png

To change the icon and text above the OpenID Connect button, see application name and logo url in appearance settings.

Disable Built-in Authentication

To remove email and password login, set the following environment variable on your Coder deployment:

CODER_DISABLE_PASSWORD_AUTH=true

SCIM

Coder supports user provisioning and deprovisioning via SCIM 2.0 with header authentication. Upon deactivation, users are suspended and are not deleted. Configure your SCIM application with an auth key and supply it the Coder server.

CODER_SCIM_API_KEY="your-api-key"

TLS

If your OpenID Connect provider requires client TLS certificates for authentication, you can configure them like so:

CODER_TLS_CLIENT_CERT_FILE=/path/to/cert.pem
CODER_TLS_CLIENT_KEY_FILE=/path/to/key.pem

Group Sync

If your OpenID Connect provider supports group claims, you can configure Coder to synchronize groups in your auth provider to groups within Coder.

To enable group sync, ensure that the groups claim is set by adding the correct scope to request. If group sync is enabled, the user's groups will be controlled by the OIDC provider. This means manual group additions/removals will be overwritten on the next login.

# as an environment variable
CODER_OIDC_SCOPES=openid,profile,email,groups
# as a flag
--oidc-scopes openid,profile,email,groups

With the groups scope requested, we also need to map the groups claim name. Coder recommends using groups for the claim name. This step is necessary if your scope's name is something other than groups.

# as an environment variable
CODER_OIDC_GROUP_FIELD=groups
# as a flag
--oidc-group-field groups

On login, users will automatically be assigned to groups that have matching names in Coder and removed from groups that the user no longer belongs to.

For cases when an OIDC provider only returns group IDs (Azure AD) or you want to have different group names in Coder than in your OIDC provider, you can configure mapping between the two.

# as an environment variable
CODER_OIDC_GROUP_MAPPING='{"myOIDCGroupID": "myCoderGroupName"}'
# as a flag
--oidc-group-mapping '{"myOIDCGroupID": "myCoderGroupName"}'

Below is an example mapping in the Coder Helm chart:

coder:
  env:
    - name: CODER_OIDC_GROUP_MAPPING
      value: >
        {"myOIDCGroupID": "myCoderGroupName"}

From the example above, users that belong to the myOIDCGroupID group in your OIDC provider will be added to the myCoderGroupName group in Coder.

Note: Groups are only updated on login.

Group allowlist

You can limit which groups from your identity provider can log in to Coder with CODER_OIDC_ALLOWED_GROUPS. Users who are not in a matching group will see the following error:

Unauthorized group error

Role sync

If your OpenID Connect provider supports roles claims, you can configure Coder to synchronize roles in your auth provider to deployment-wide roles within Coder.

Set the following in your Coder server configuration.

 # Depending on your identity provider configuration, you may need to explicitly request a "roles" scope
CODER_OIDC_SCOPES=openid,profile,email,roles

# The following fields are required for role sync:
CODER_OIDC_USER_ROLE_FIELD=roles
CODER_OIDC_USER_ROLE_MAPPING='{"TemplateAuthor":["template-admin","user-admin"]}'

One role from your identity provider can be mapped to many roles in Coder (e.g. the example above maps to 2 roles in Coder.)

Troubleshooting group/role sync

Some common issues when enabling group/role sync.

General guidelines

If you are running into issues with group/role sync, is best to view your Coder server logs and enable verbose mode. To reduce noise, you can filter for only logs related to group/role sync:

CODER_VERBOSE=true
CODER_LOG_FILTER=".*userauth.*|.*groups returned.*"

Be sure to restart the server after changing these configuration values. Then, attempt to log in, preferably with a user who has the Owner role.

The logs for a successful group sync look like this (human-readable):

[debu]  coderd.userauth: got oidc claims  request_id=49e86507-6842-4b0b-94d4-f245e62e49f3  source=id_token  claim_fields="[aio aud email exp groups iat idp iss name nbf oid preferred_username rh sub tid uti ver]"  blank=[]

[debu]  coderd.userauth: got oidc claims  request_id=49e86507-6842-4b0b-94d4-f245e62e49f3  source=userinfo  claim_fields="[email family_name given_name name picture sub]"  blank=[]

[debu]  coderd.userauth: got oidc claims  request_id=49e86507-6842-4b0b-94d4-f245e62e49f3  source=merged  claim_fields="[aio aud email exp family_name given_name groups iat idp iss name nbf oid picture preferred_username rh sub tid uti ver]"  blank=[]

[debu]  coderd: groups returned in oidc claims  request_id=49e86507-6842-4b0b-94d4-f245e62e49f3  [email protected]  username=ben  len=3  groups="[c8048e91-f5c3-47e5-9693-834de84034ad 66ad2cc3-a42f-4574-a281-40d1922e5b65 70b48175-107b-4ad8-b405-4d888a1c466f]"

To view the full claim, the Owner role can visit this endpoint on their Coder deployment after logging in:

https://[coder.example.com]/api/v2/debug/[username]/debug-link

User not being assigned / Group does not exist

If you want Coder to create groups that do not exist, you can set the following environment variable. If you enable this, your OIDC provider might be sending over many unnecessary groups. Use filtering options on the OIDC provider to limit the groups sent over to prevent creating excess groups.

# as an environment variable
CODER_OIDC_GROUP_AUTO_CREATE=true
# as a flag
--oidc-group-auto-create=true

A basic regex filtering option on the Coder side is available. This is applied after the group mapping (CODER_OIDC_GROUP_MAPPING), meaning if the group is remapped, the remapped value is tested in the regex. This is useful if you want to filter out groups that do not match a certain pattern. For example, if you want to only allow groups that start with my-group- to be created, you can set the following environment variable.

# as an environment variable
CODER_OIDC_GROUP_REGEX_FILTER="^my-group-.*$"
# as a flag
--oidc-group-regex-filter="^my-group-.*$"

Invalid Scope

If you see an error like the following, you may have an invalid scope.

The application '<oidc_application>' asked for scope 'groups' that doesn't exist on the resource...

This can happen because the identity provider has a different name for the scope. For example, Azure AD uses GroupMember.Read.All instead of groups. You can find the correct scope name in the IDP's documentation. Some IDP's allow configuring the name of this scope.

The solution is to update the value of CODER_OIDC_SCOPES to the correct value for the identity provider.

No group claim in the got oidc claims log

Steps to troubleshoot.

  1. Ensure the user is a part of a group in the IDP. If the user has 0 groups, no groups claim will be sent.
  2. Check if another claim appears to be the correct claim with a different name. A common name is memberOf instead of groups. If this is present, update CODER_OIDC_GROUP_FIELD=memberOf.
  3. Make sure the number of groups being sent is under the limit of the IDP. Some IDPs will return an error, while others will just omit the groups claim. A common solution is to create a filter on the identity provider that returns less than the limit for your IDP.

Provider-Specific Guides

Below are some details specific to individual OIDC providers.

Active Directory Federation Services (ADFS)

Note: Tested on ADFS 4.0, Windows Server 2019

  1. In your Federation Server, create a new application group for Coder. Follow the steps as described here.

    • Server Application: Note the Client ID.
    • Configure Application Credentials: Note the Client Secret.
    • Configure Web API: Set the Client ID as the relying party identifier.
    • Application Permissions: Allow access to the claims openid, email, profile, and allatclaims.
  2. Visit your ADFS server's /.well-known/openid-configuration URL and note the value for issuer.

    Note: This is usually of the form https://adfs.corp/adfs/.well-known/openid-configuration

  3. In Coder's configuration file (or Helm values as appropriate), set the following environment variables or their corresponding CLI arguments:

    • CODER_OIDC_ISSUER_URL: the issuer value from the previous step.

    • CODER_OIDC_CLIENT_ID: the Client ID from step 1.

    • CODER_OIDC_CLIENT_SECRET: the Client Secret from step 1.

    • CODER_OIDC_AUTH_URL_PARAMS: set to

      {"resource":"$CLIENT_ID"}


      where $CLIENT_ID is the Client ID from step 1 (see here). This is required for the upstream OIDC provider to return the requested claims.

    • CODER_OIDC_IGNORE_USERINFO: Set to true.

  4. Configure Issuance Transform Rules on your federation server to send the following claims:

    • preferred_username: You can use e.g. "Display Name" as required.

    • email: You can use e.g. the LDAP attribute "E-Mail-Addresses" as required.

    • email_verified: Create a custom claim rule:

      => issue(Type = "email_verified", Value = "true")

    • (Optional) If using Group Sync, send the required groups in the configured groups claim field. See here for an example.

Keycloak

The access_type parameter has two possible values: "online" and "offline." By default, the value is set to "offline". This means that when a user authenticates using OIDC, the application requests offline access to the user's resources, including the ability to refresh access tokens without requiring the user to reauthenticate.

To enable the offline_access scope, which allows for the refresh token functionality, you need to add it to the list of requested scopes during the authentication flow. Including the offline_access scope in the requested scopes ensures that the user is granted the necessary permissions to obtain refresh tokens.

By combining the {"access_type":"offline"} parameter in the OIDC Auth URL with the offline_access scope, you can achieve the desired behavior of obtaining refresh tokens for offline access to the user's resources.

See an opportunity to improve our docs? Make an edit.
