JFrog Artifactory
Use Coder and JFrog Artifactory together to secure your development environments without disturbing your developers' existing workflows.
This guide will demonstrate how to use JFrog Artifactory as a package registry within a workspace.
Requirements
- A JFrog Artifactory instance
- 1:1 mapping of users in Coder to users in Artifactory by email address or username
- Repositories configured in Artifactory for each package manager you want to use
Provisioner Authentication
The most straight-forward way to authenticate your template with Artifactory is by using our official Coder modules. We publish two type of modules that automate the JFrog Artifactory and Coder integration.
JFrog-OAuth
This module is usable by JFrog self-hosted (on-premises) Artifactory as it requires configuring a custom integration. This integration benefits from Coder's external-auth feature and allows each user to authenticate with Artifactory using an OAuth flow and issues user-scoped tokens to each user.
To set this up, follow these steps:
- Modify your Helm chart
values.yaml
for JFrog Artifactory to add,
artifactory:
enabled: true
frontend:
extraEnvironmentVariables:
- name: JF_FRONTEND_FEATURETOGGLER_ACCESSINTEGRATION
value: "true"
access:
accessConfig:
integrations-enabled: true
integration-templates:
- id: "1"
name: "CODER"
redirect-uri: "https://CODER_URL/external-auth/jfrog/callback"
scope: "applied-permissions/user"
Note Replace
CODER_URL
with your Coder deployment URL, e.g., <coder.example.com>
- Create a new Application Integration by going to https://JFROG_URL/ui/admin/configuration/integrations/new and select the Application Type as the integration you created in step 1.
- Add a new external authentication to Coder by setting these env variables,
# JFrog Artifactory External Auth
CODER_EXTERNAL_AUTH_1_ID="jfrog"
CODER_EXTERNAL_AUTH_1_TYPE="jfrog"
CODER_EXTERNAL_AUTH_1_CLIENT_ID="YYYYYYYYYYYYYYY"
CODER_EXTERNAL_AUTH_1_CLIENT_SECRET="XXXXXXXXXXXXXXXXXXX"
CODER_EXTERNAL_AUTH_1_DISPLAY_NAME="JFrog Artifactory"
CODER_EXTERNAL_AUTH_1_DISPLAY_ICON="/icon/jfrog.svg"
CODER_EXTERNAL_AUTH_1_AUTH_URL="https://JFROG_URL/ui/authorization"
CODER_EXTERNAL_AUTH_1_SCOPES="applied-permissions/user"
Note Replace
JFROG_URL
with your JFrog Artifactory base URL, e.g., <example.jfrog.io>
- Create or edit a Coder template and use the JFrog-OAuth module to configure the integration.
module "jfrog" {
source = "registry.coder.com/modules/jfrog-oauth/coder"
version = "1.0.0"
agent_id = coder_agent.example.id
jfrog_url = "https://jfrog.example.com"
configure_code_server = true # this depends on the code-server
username_field = "username" # If you are using GitHub to login to both Coder and Artifactory, use username_field = "username"
package_managers = {
"npm": "npm",
"go": "go",
"pypi": "pypi"
}
}
JFrog-Token
This module makes use of the Artifactory terraform provider and an admin-scoped token to create user-scoped tokens for each user by matching their Coder email or username with Artifactory. This can be used for both SaaS and self-hosted(on-premises) Artifactory instances.
To set this up, follow these steps:
- Get a JFrog access token from your Artifactory instance. The token must be an
admin token
with scope
applied-permissions/admin
. - Create or edit a Coder template and use the JFrog-Token module to configure the integration and pass the admin token. It is recommended to store the token in a sensitive terraform variable to prevent it from being displayed in plain text in the terraform state.
variable "artifactory_access_token" {
type = string
sensitive = true
}
module "jfrog" {
source = "registry.coder.com/modules/jfrog-token/coder"
version = "1.0.0"
agent_id = coder_agent.example.id
jfrog_url = "https://example.jfrog.io"
configure_code_server = true # this depends on the code-server
artifactory_access_token = var.artifactory_access_token
package_managers = {
"npm": "npm",
"go": "go",
"pypi": "pypi"
}
}
The admin-level access token is used to provision user tokens and is never exposed to developers or stored in workspaces.
If you do not want to use the official modules, you can check example template that uses Docker as the underlying compute here. The same concepts apply to all compute types.
Offline Deployments
See the offline deployments section for instructions on how to use coder-modules in an offline environment with Artifactory.
More reading
- See the full example template here.
- To serve extensions from your own VS Code Marketplace, check out code-marketplace.
