Scale Testing
Scaling Coder involves planning and testing to ensure it can handle more load without compromising service. This process encompasses infrastructure setup, traffic projections, and aggressive testing to identify and mitigate potential bottlenecks.
A dedicated Kubernetes cluster for Coder is recommended to configure, host and manage Coder workloads. Kubernetes provides container orchestration capabilities, allowing Coder to efficiently deploy, scale, and manage workspaces across a distributed infrastructure. This ensures high availability, fault tolerance, and scalability for Coder deployments. Coder is deployed on this cluster using the Helm chart.
Methodology
Our scale tests include the following stages:
-
Prepare environment: create expected users and provision workspaces.
-
SSH connections: establish user connections with agents, verifying their ability to echo back received content.
-
Web Terminal: verify the PTY connection used for communication with Web Terminal.
-
Workspace application traffic: assess the handling of user connections with specific workspace apps, confirming their capability to echo back received content effectively.
-
Dashboard evaluation: verify the responsiveness and stability of Coder dashboards under varying load conditions. This is achieved by simulating user interactions using instances of headless Chromium browsers.
-
Cleanup: delete workspaces and users created in step 1.
Infrastructure and setup requirements
The scale tests runner can distribute the workload to overlap single scenarios based on the workflow configuration:
T0 | T1 | T2 | T3 | T4 | T5 | T6 | |
---|---|---|---|---|---|---|---|
SSH connections | X | X | X | X | |||
Web Terminal (PTY) | X | X | X | X | |||
Workspace apps | X | X | X | X | |||
Dashboard (headless) | X | X | X | X |
This pattern closely reflects how our customers naturally use the system. SSH connections are heavily utilized because they're the primary communication channel for IDEs with VS Code and JetBrains plugins.
The basic setup of scale tests environment involves:
- Scale tests runner (32 vCPU, 128 GB RAM)
- Coder: 2 replicas (4 vCPU, 16 GB RAM)
- Database: 1 instance (2 vCPU, 32 GB RAM)
- Provisioner: 50 instances (0.5 vCPU, 512 MB RAM)
The test is deemed successful if users did not experience interruptions in their
workflows, coderd
did not crash or require restarts, and no other internal
errors were observed.
Traffic Projections
In our scale tests, we simulate activity from 2000 users, 2000 workspaces, and 2000 agents, with two items of workspace agent metadata being sent every 10 seconds. Here are the resulting metrics:
Coder:
- Median CPU usage for coderd: 3 vCPU, peaking at 3.7 vCPU while all tests are running concurrently.
- Median API request rate: 350 RPS during dashboard tests, 250 RPS during Web Terminal and workspace apps tests.
- 2000 agent API connections with latency: p90 at 60 ms, p95 at 220 ms.
- on average 2400 Web Socket connections during dashboard tests.
Provisionerd:
- Median CPU usage is 0.35 vCPU during workspace provisioning.
Database:
- Median CPU utilization is 80%, with a significant portion dedicated to writing workspace agent metadata.
- Memory utilization averages at 40%.
write_ops_count
between 6.7 and 8.4 operations per second.
Available reference architectures
Hardware recommendation
Control plane: coderd
To ensure stability and reliability of the Coder control plane, it's essential to focus on node sizing, resource limits, and the number of replicas. We recommend referencing public cloud providers such as AWS, GCP, and Azure for guidance on optimal configurations. A reasonable approach involves using scaling formulas based on factors like CPU, memory, and the number of users.
While the minimum requirements specify 1 CPU core and 2 GB of memory per
coderd
replica, it is recommended to allocate additional resources depending
on the workload size to ensure deployment stability.
CPU and memory usage
Enabling agent stats collection (optional) may increase memory consumption.
Enabling direct connections between users and workspace agents (apps or SSH traffic) can help prevent an increase in CPU usage. It is recommended to keep this option enabled unless there are compelling reasons to disable it.
Inactive users do not consume Coder resources.
Scaling formula
When determining scaling requirements, consider the following factors:
1 vCPU x 2 GB memory
for every 250 users: A reasonable formula to determine resource allocation based on the number of users and their expected usage patterns.- API latency/response time: Monitor API latency and response times to ensure optimal performance under varying loads.
- Average number of HTTP requests: Track the average number of HTTP requests to gauge system usage and identify potential bottlenecks. The number of proxied connections: For a very high number of proxied connections, more memory is required.
HTTP API latency
For a reliable Coder deployment dealing with medium to high loads, it's important that API calls for workspace/template queries and workspace build operations respond within 300 ms. However, API template insights calls, which involve browsing workspace agent stats and user activity data, may require more time. Moreover, Coder API exposes WebSocket long-lived connections for Web Terminal (bidirectional), and Workspace events/logs (unidirectional).
If the Coder deployment expects traffic from developers spread across the globe, be aware that customer-facing latency might be higher because of the distance between users and the load balancer. Fortunately, the latency can be improved with a deployment of Coder workspace proxies.
Node Autoscaling
We recommend disabling the autoscaling for coderd
nodes. Autoscaling can cause
interruptions for user connections, see
Autoscaling for more details.
Control plane: Workspace Proxies
When scaling workspace proxies, follow the
same guidelines as for coderd
above:
1 vCPU x 2 GB memory
for every 250 users.- Disable autoscaling.
Control plane: provisionerd
Each external provisioner can run a single concurrent workspace build. For example, running 10 provisioner containers will allow 10 users to start workspaces at the same time.
By default, the Coder server runs 3 built-in provisioner daemons, but the
Premium Coder release allows for running external provisioners to separate the
load caused by workspace provisioning on the coderd
nodes.
Scaling formula
When determining scaling requirements, consider the following factors:
1 vCPU x 1 GB memory x 2 concurrent workspace build
: A formula to determine resource allocation based on the number of concurrent workspace builds, and standard complexity of a Terraform template. Rule of thumb: the more provisioners are free/available, the more concurrent workspace builds can be performed.
Node Autoscaling
Autoscaling provisioners is not an easy problem to solve unless it can be predicted when a number of concurrent workspace builds increases.
We recommend disabling autoscaling and adjusting the number of provisioners to developer needs based on the workspace build queuing time.
Data plane: Workspaces
To determine workspace resource limits and keep the best developer experience for workspace users, administrators must be aware of a few assumptions.
- Workspace pods run on the same Kubernetes cluster, but possibly in a different namespace or on a separate set of nodes.
- Workspace limits (per workspace user):
- Evaluate the workspace utilization pattern. For instance, web application development does not require high CPU capacity at all times, but will spike during builds or testing.
- Evaluate minimal limits for single workspace. Include in the calculation requirements for Coder agent running in an idle workspace - 0.1 vCPU and 256 MB. For instance, developers can choose between 0.5-8 vCPUs, and 1-16 GB memory.
Scaling formula
When determining scaling requirements, consider the following factors:
1 vCPU x 2 GB memory x 1 workspace
: A formula to determine resource allocation based on the minimal requirements for an idle workspace with a running Coder agent and occasional CPU and memory bursts for building projects.
Node Autoscaling
Workspace nodes can be set to operate in autoscaling mode to mitigate the risk of prolonged high resource utilization.
One approach is to scale up workspace nodes when total CPU usage or memory consumption reaches 80%. Another option is to scale based on metrics such as the number of workspaces or active users. It's important to note that as new users onboard, the autoscaling configuration should account for ongoing workspaces.
Scaling down workspace nodes to zero is not recommended, as it will result in longer wait times for workspace provisioning by users. However, this may be necessary for workspaces with special resource requirements (e.g. GPUs) that incur significant cost overheads.
