Reference Architectures

Reference Architectures

This document provides prescriptive solutions and reference architectures to support successful deployments of up to 3000 users and outlines at a high-level the methodology currently used to scale-test Coder.

General concepts

This section outlines core concepts and terminology essential for understanding Coder's architecture and deployment strategies.

Administrator

An administrator is a user role within the Coder platform with elevated privileges. Admins have access to administrative functions such as user management, template definitions, insights, and deployment configuration.

Coder

Coder, also known as coderd, is the main service recommended for deployment with multiple replicas to ensure high availability. It provides an API for managing workspaces and templates. Each coderd replica has the capability to host multiple provisioners.

User

A user is an individual who utilizes the Coder platform to develop, test, and deploy applications using workspaces. Users can select available templates to provision workspaces. They interact with Coder using the web interface, the CLI tool, or directly calling API methods.

Workspace

A workspace refers to an isolated development environment where users can write, build, and run code. Workspaces are fully configurable and can be tailored to specific project requirements, providing developers with a consistent and efficient development environment. Workspaces can be autostarted and autostopped, enabling efficient resource management.

Users can connect to workspaces using SSH or via workspace applications like code-server, facilitating collaboration and remote access. Additionally, workspaces can be parameterized, allowing users to customize settings and configurations based on their unique needs. Workspaces are instantiated using Coder templates and deployed on resources created by provisioners.

Template

A template in Coder is a predefined configuration for creating workspaces. Templates streamline the process of workspace creation by providing pre-configured settings, tooling, and dependencies. They are built by template administrators on top of Terraform, allowing for efficient management of infrastructure resources. Additionally, templates can utilize Coder modules to leverage existing features shared with other templates, enhancing flexibility and consistency across deployments. Templates describe provisioning rules for infrastructure resources offered by Terraform providers.

Workspace Proxy

A workspace proxy serves as a relay connection option for developers connecting to their workspace over SSH, a workspace app, or through port forwarding. It helps reduce network latency for geo-distributed teams by minimizing the distance network traffic needs to travel. Notably, workspace proxies do not handle dashboard connections or API calls.

Provisioner

Provisioners in Coder execute Terraform during workspace and template builds. While the platform includes built-in provisioner daemons by default, there are advantages to employing external provisioners. These external daemons provide secure build environments and reduce server load, improving performance and scalability. Each provisioner can handle a single concurrent workspace build, allowing for efficient resource allocation and workload management.

Registry

The Coder Registry is a platform where you can find starter templates and Modules for various cloud services and platforms.

Templates help create self-service development environments using Terraform-defined infrastructure, while Modules simplify template creation by providing common features like workspace applications, third-party integrations, or helper scripts.

Please note that the Registry is a hosted service and isn't available for offline use.

Scale-testing methodology

Scaling Coder involves planning and testing to ensure it can handle more load without compromising service. This process encompasses infrastructure setup, traffic projections, and aggressive testing to identify and mitigate potential bottlenecks.

A dedicated Kubernetes cluster for Coder is Kubernetes cluster specifically configured to host and manage Coder workloads. Kubernetes provides container orchestration capabilities, allowing Coder to efficiently deploy, scale, and manage workspaces across a distributed infrastructure. This ensures high availability, fault tolerance, and scalability for Coder deployments. Code is deployed on this cluster using the Helm chart.

Our scale tests include the following stages:

  1. Prepare environment: create expected users and provision workspaces.

  2. SSH connections: establish user connections with agents, verifying their ability to echo back received content.

  3. Web Terminal: verify the PTY connection used for communication with Web Terminal.

  4. Workspace application traffic: assess the handling of user connections with specific workspace apps, confirming their capability to echo back received content effectively.

  5. Dashboard evaluation: verify the responsiveness and stability of Coder dashboards under varying load conditions. This is achieved by simulating user interactions using instances of headless Chromium browsers.

  6. Cleanup: delete workspaces and users created in step 1.

Infrastructure and setup requirements

The scale tests runner can distribute the workload to overlap single scenarios based on the workflow configuration:

T0T1T2T3T4T5T6
SSH connectionsXXXX
Web Terminal (PTY)XXXX
Workspace appsXXXX
Dashboard (headless)XXXX

This pattern closely reflects how our customers naturally use the system. SSH connections are heavily utilized because they're the primary communication channel for IDEs with VS Code and JetBrains plugins.

The basic setup of scale tests environment involves:

  1. Scale tests runner (32 vCPU, 128 GB RAM)
  2. Coder: 2 replicas (4 vCPU, 16 GB RAM)
  3. Database: 1 instance (2 vCPU, 32 GB RAM)
  4. Provisioner: 50 instances (0.5 vCPU, 512 MB RAM)

The test is deemed successful if users did not experience interruptions in their workflows, coderd did not crash or require restarts, and no other internal errors were observed.

Traffic Projections

In our scale tests, we simulate activity from 2000 users, 2000 workspaces, and 2000 agents, with two items of workspace agent metadata being sent every 10 seconds. Here are the resulting metrics:

Coder:

  • Median CPU usage for coderd: 3 vCPU, peaking at 3.7 vCPU while all tests are running concurrently.
  • Median API request rate: 350 RPS during dashboard tests, 250 RPS during Web Terminal and workspace apps tests.
  • 2000 agent API connections with latency: p90 at 60 ms, p95 at 220 ms.
  • on average 2400 Web Socket connections during dashboard tests.

Provisionerd:

  • Median CPU usage is 0.35 vCPU during workspace provisioning.

Database:

  • Median CPU utilization is 80%, with a significant portion dedicated to writing workspace agent metadata.
  • Memory utilization averages at 40%.
  • write_ops_count between 6.7 and 8.4 operations per second.

Available reference architectures

Up to 1,000 users

Up to 2,000 users

Up to 3,000 users

Hardware recommendation

Control plane: coderd

To ensure stability and reliability of the Coder control plane, it's essential to focus on node sizing, resource limits, and the number of replicas. We recommend referencing public cloud providers such as AWS, GCP, and Azure for guidance on optimal configurations. A reasonable approach involves using scaling formulas based on factors like CPU, memory, and the number of users.

While the minimum requirements specify 1 CPU core and 2 GB of memory per coderd replica, it is recommended to allocate additional resources depending on the workload size to ensure deployment stability.

CPU and memory usage

Enabling agent stats collection (optional) may increase memory consumption.

Enabling direct connections between users and workspace agents (apps or SSH traffic) can help prevent an increase in CPU usage. It is recommended to keep this option enabled unless there are compelling reasons to disable it.

Inactive users do not consume Coder resources.

Scaling formula

When determining scaling requirements, consider the following factors:

  • 1 vCPU x 2 GB memory x 250 users: A reasonable formula to determine resource allocation based on the number of users and their expected usage patterns.
  • API latency/response time: Monitor API latency and response times to ensure optimal performance under varying loads.
  • Average number of HTTP requests: Track the average number of HTTP requests to gauge system usage and identify potential bottlenecks. The number of proxied connections: For a very high number of proxied connections, more memory is required.

HTTP API latency

For a reliable Coder deployment dealing with medium to high loads, it's important that API calls for workspace/template queries and workspace build operations respond within 300 ms. However, API template insights calls, which involve browsing workspace agent stats and user activity data, may require more time. Moreover, Coder API exposes WebSocket long-lived connections for Web Terminal (bidirectional), and Workspace events/logs (unidirectional).

If the Coder deployment expects traffic from developers spread across the globe, be aware that customer-facing latency might be higher because of the distance between users and the load balancer. Fortunately, the latency can be improved with a deployment of Coder workspace proxies.

Node Autoscaling

We recommend disabling the autoscaling for coderd nodes. Autoscaling can cause interruptions for user connections, see Autoscaling for more details.

Control plane: provisionerd

Each external provisioner can run a single concurrent workspace build. For example, running 10 provisioner containers will allow 10 users to start workspaces at the same time.

By default, the Coder server runs 3 built-in provisioner daemons, but the Enterprise Coder release allows for running external provisioners to separate the load caused by workspace provisioning on the coderd nodes.

Scaling formula

When determining scaling requirements, consider the following factors:

  • 1 vCPU x 1 GB memory x 2 concurrent workspace build: A formula to determine resource allocation based on the number of concurrent workspace builds, and standard complexity of a Terraform template. Rule of thumb: the more provisioners are free/available, the more concurrent workspace builds can be performed.

Node Autoscaling

Autoscaling provisioners is not an easy problem to solve unless it can be predicted when a number of concurrent workspace builds increases.

We recommend disabling autoscaling and adjusting the number of provisioners to developer needs based on the workspace build queuing time.

Data plane: Workspaces

To determine workspace resource limits and keep the best developer experience for workspace users, administrators must be aware of a few assumptions.

  • Workspace pods run on the same Kubernetes cluster, but possibly in a different namespace or on a separate set of nodes.
  • Workspace limits (per workspace user):
    • Evaluate the workspace utilization pattern. For instance, web application development does not require high CPU capacity at all times, but will spike during builds or testing.
    • Evaluate minimal limits for single workspace. Include in the calculation requirements for Coder agent running in an idle workspace - 0.1 vCPU and 256 MB. For instance, developers can choose between 0.5-8 vCPUs, and 1-16 GB memory.

Scaling formula

When determining scaling requirements, consider the following factors:

  • 1 vCPU x 2 GB memory x 1 workspace: A formula to determine resource allocation based on the minimal requirements for an idle workspace with a running Coder agent and occasional CPU and memory bursts for building projects.

Node Autoscaling

Workspace nodes can be set to operate in autoscaling mode to mitigate the risk of prolonged high resource utilization.

One approach is to scale up workspace nodes when total CPU usage or memory consumption reaches 80%. Another option is to scale based on metrics such as the number of workspaces or active users. It's important to note that as new users onboard, the autoscaling configuration should account for ongoing workspaces.

Scaling down workspace nodes to zero is not recommended, as it will result in longer wait times for workspace provisioning by users. However, this may be necessary for workspaces with special resource requirements (e.g. GPUs) that incur significant cost overheads.

Data plane: External database

While running in production, Coder requires a access to an external PostgreSQL database. Depending on the scale of the user-base, workspace activity, and High Availability requirements, the amount of CPU and memory resources required by Coder's database may differ.

Scaling formula

When determining scaling requirements, take into account the following considerations:

  • 2 vCPU x 8 GB RAM x 512 GB storage: A baseline for database requirements for Coder deployment with less than 1000 users, and low activity level (30% active users). This capacity should be sufficient to support 100 external provisioners.
  • Storage size depends on user activity, workspace builds, log verbosity, overhead on database encryption, etc.
  • Allocate two additional CPU core to the database instance for every 1000 active users.
  • Enable High Availability mode for database engine for large scale deployments.

If you enable database encryption in Coder, consider allocating an additional CPU core to every coderd replica.

Performance optimization guidelines

We provide the following general recommendations for PostgreSQL settings:

  • Increase number of vCPU if CPU utilization or database latency is high.
  • Allocate extra memory if database performance is poor, CPU utilization is low, and memory utilization is high.
  • Utilize faster disk options (higher IOPS) such as SSDs or NVMe drives for optimal performance enhancement and possibly reduce database load.

Operational readiness

Operational readiness in Coder is about ensuring that everything is set up correctly before launching a platform into production. It involves making sure that the service is reliable, secure, and easily scales accordingly to user-base needs. Operational readiness is crucial because it helps prevent issues that could affect workspace users experience once the platform is live.

Learn about Coder design principles and architectural best practices described in the Well-Architected Framework.

Configuration

  1. Identify the required Helm values for configuration.
  2. Create values.yaml and add it to a version control system. Note: it is highly recommended that you create a custom values.yaml as opposed to copying the entire default values.
  3. Determine the necessary environment variables.

Template configuration

  1. Establish a dedicated user account for the Template Administrator.
  2. Maintain Coder templates using version control.
  3. Consider implementing a GitOps workflow to automatically push new template. For example, on Github, you can use the Update Coder Template action.
  4. Evaluate enabling automatic template updates upon workspace startup.

Deployment

  1. Leverage automation tooling to automate deployment and upgrades of Coder.

Observability

  1. Enable the Prometheus endpoint (environment variable: CODER_PROMETHEUS_ENABLE).
  2. Deploy a visual monitoring system such as Grafana for metrics visualization.
  3. Deploy a centralized logs aggregation solution to collect and monitor application logs.
  4. Review the Prometheus response and set up alarms on selected metrics.

Database backups

  1. Prepare internal scripts for dumping and restoring databases.
  2. Schedule regular database backups, especially before release upgrades.

User support

  1. Incorporate support links into internal documentation accessible from the user context menu. Ensure that hyperlinks are valid and lead to up-to-date materials.
  2. Encourage the use of coder support bundle to allow workspace users to generate and provide network-related diagnostic data.
